Square D - Molded Case Circuit Breakers

Square D / Schneider Electric HLP36125 Specifications:

• MOLDED CASE
• THERMAL MAGNETIC TYPE
• 4.12 INCH W X 4.36 INCH D X 6.4 INCH H SIZE
• 600 V MAX. AC VOLTAGE RATING
• 250 V MAX. DC VOLTAGE RATING
• UL
• CSA APPROVAL
• 240/480/600 VAC AT 50/60 HZ
• 480 VAC STAR/277 VAC AT 50/60 HZ
• 600 VAC STAR/347 VAC AT 50/60 HZ (UL/CSA/NOM)
• 240/415 VAC AT 50/60 HZ (IEC)
• 250 VDC VOLTAGE RATING
• 125 KILOAMPERE AT 240 VAC
• 100 KILOAMPERE AT 480 VAC STAR/277 VAC OR 480 VAC
• 50 KILOAMPERE AT 600 VAC STAR/347 VAC OR 600 VAC (UL/CSA/NOM)
• 125 KILOAMPERE AT 240 VAC
• 100 KILOAMPERE AT 415 VAC (IEC)
• 20 KILOAMPERE AT 250 VDC INTERRUPTING RATING
• 125 AMPERE CURRENT RATING
• 3 POLE(S)
• TERMINAL NUT KIT (ON END)
• LUG (OFF END) TERMINAL TYPE
• H FRAME TYPE
• POWERPACT[T] BRAND
• WIRE SIZE 14 TO 3/0 AWG (ALUMINUM/COPPER)
• HL MODEL Molded Case Circuit Breakers from Square D / Schneider Electric
