Square D
Square D / Schneider Electric 45T3HEE
Product SKU: square-d-45t3hee
Available:
Only 1 item in stock
1 item in stock
In stock
Out of stock
Back in stock
$0.00
Square D / Schneider Electric 45T3HEE
To receive a quote for square-d-45t3hee, please complete the form below. You can also talk to our expert sales team right now by calling 800-211-4962
Thank you for contacting us. Your inquiry for square-d-45t3hee was received and we will be in touch shortly. You can also call 800-211-4962 to speak to someone on our expert sales team.
Other people want this. 15 people have this in their carts right now.
Want it delivered by Saturday, 11 January
Order until 10:00 tomorrow
- Description
- Shipping & Returns
- Reviews
- Catalog Number: 45T3HEE
- Manufacturer: Square D
Square D 45T3HEE Specifications:
- TYPE EE
- PRIMARY VOLTAGE 480 V DELTA
- SECONDARY VOLTAGE 208 V STAR/120 V
- 60 HZ
- POWER RATING 45 KVA
- 3 PHASE
- TAPS (2) +2.5 PERCENT X (4) -2.5 PERCENT
- TEMPERATURE RISE 150 DEG C
- FLOOR MOUNTING
- NEMA 2
- SIZE 20 INCH W X 20 INCH D X 30 INCH H
Square D 45T3HEE Details:
- Directory:: CIS
- Commerce Sector:: Construction Materials
- Industry:: Electrical
- Commodity Code:: 3910
- Commodity Description:: Power Transformers, etc. - Distribution Transformers
- UPC:: 78590135351
- Item Number:: 35351
- Catalog Number:: 45T3HEE
- UNSPSC:: 39121001
- Model:: 7400
- Type Designation:: EE
- Primary Voltage:: 480 V DELTA
- Secondary Voltage:: 208 V STAR/120 V
- Frequency Rating:: 60 HZ
- Power Rating:: 45 KVA
- Power Rating in KVA:: 45
- Power Rating in KVA - UOM:: kVA
- Number of Phases:: 3
- Taps:: (2) +2.5 PERCENT X (4) -2.5 PERCENT
- Temperature Rise:: 150 DEG C
- Mounting:: FLOOR
- Enclosure:: NEMA 2
- Size:: 20 INCH W X 20 INCH D X 30 INCH H
- Weight:: 382 LB
- Application:: INDOOR
- Additional Information:: APPLICABLE STANDARD NEMA TP-1
