FA26030AC1202 30A 2P 600V AC PHASE WITH AUXILIARY SWITCH THERMAL MAGNETIC MCCB

Square D / Schneider Electric FA26030AC1202 Specifications:

• CLASS 650/651 I-LINE[R] PANELBOARD/SWITCHBOARD USED ON
• UL
• CSA APPROVAL
• POWER DISTRIBUTION APPLICATION
• 240/480/600 VAC AT 50/60 HZ
• 480 VAC STAR/277 VAC AT 50/60 HZ
• 600 VAC STAR/347 VAC AT 50/60 HZ (UL/CSA/NOM)
• 415 VAC AT 50/60 HZ (IEC)
• 250 VDC VOLTAGE RATING
• 10/25 KILOAMPERE AT 240 VAC
• 18 KILOAMPERE AT 480 VAC STAR/277 VAC OR 480 VAC
• 14 KILOAMPERE AT 600 VAC STAR/347 VAC OR 600 VAC (UL/CSA/NOM)
• 10 KILOAMPERE AT 415 VAC (IEC)
• 10 KILOAMPERE AT 250 VDC INTERRUPTING RATING
• 50 AMPERE CURRENT RATING
• 2 POLE(S)
• 400 TO 850 AMPERE TRIP SETTING
• I-LINE[R] BRAND
• FRAME TYPE F
• MOUNTING TYPE PLUG ON
• TERMINAL WIRE SIZE 12 TO 1/0 AWG (ALUMINUM)
• 14 TO 1/0 AWG (COPPER)
• SIZE 3 INCH W X 4.13 INCH D X 6 INCH H
• TRIPPING METHOD THERMAL MAGNETIC
• WITH RED/BLUE PHASE
• FA MODEL Molded Case Circuit Breakers from Square D / Schneider Electric
