Cutler Hammer ECE09F1BAA-R22

Cutler Hammer ECE09F1BAA-R22 Details:

• Directory:: CIS
• Commerce Sector:: Construction Materials
• Industry:: Electrical
• Commodity Code:: 4130
• Commodity Description:: Motor Cntrl Starters, etc. - Motor Cntrl Starters & Cntctrs
• UPC:: 78211426276
• Item Number:: 26276
• Catalog Number:: ECE09F1BAA-R22
• UNSPSC:: 39121521
• Model:: ECE
• Type:: FULL VOLTAGE, NON COMBINATION, NON REVERSING
• Power Rating/Voltage:: 5 HP AT 230 V 1 PHASE, 10 HP AT 230 V 3 PHASE, 15 HP AT 380 V 3 PHASE 50 HZ
• Current Rating:: 32 AMPERE (UL, IEC THERMAL CURRENT)
• Phase:: 1/3
• Coil Voltage:: 220 V AT 50 HZ, 240 V AT 60 HZ
• Motor FLA:: 18 TO 24 AMPERE
• Auxiliary Contact:: 1NO
• Size:: IEC F
• Enclosure Type:: NEMA 1, IP40
• Overloads:: BIMETALLIC AMBIENT TEMPERATURE COMPENSATED 1NO-1NC AUTOMATIC/MANUAL RESET CLASS 10, OVERLOAD CURRENT RANGE 18 TO 24 AMPERE
• Construction Standard:: IEC
• Additional Information:: APPROVAL UL, CSA
• ::
